特點介紹：

合模部分 CLAMPING UNIT
1、大拉桿內距,寬模板設計,模具適應范圍廣。
      Enlarged tie-bar distance, more molds can be used.
2、QT500-7球墨鑄鐵高剛性的模板設計,配合高安全系數的拉桿,整體提升合模結
      構的剛性及穩定性。
      The high rigidity formwork design of QT500-7 nodular cast
       iron, combined with the pull rod with high safety factor,
       improves the rigidity and stability of the clamping structure
       as a whole.
3、T型槽模板,方便模具的更換。
    “T ”groove templates is quite easy to change for mould.
4、可選配中心頂出強制復位功能。
      Optional center ejection forced reset function.
5、ZS1200及以上機型標配動板定位環安裝位置。
     ZS1200 and above models are equipped with standard
     moving plate locating ring installation position.

注射部分 INJECTION UNIT

1、注射單元采用模組化的托板座設計,一線式雙缸平衡注射裝置,

      使螺桿在注塑過程中受力平均。
      Modular injection unit design with dragging plate structure, in-line type twin
      inject cylinders,working smoothly during injection process.
2、獨特高混煉的注塑螺桿組件設計,具有高塑化效率和高耐磨性。
      Innovative screw design have good maxing effect, high plasticizing capacity.
3、料筒標配陶瓷加熱圈，標配射臺潤滑手動油泵。
      The barrel is equipped with ceramic heating ring as standard, and the
      injection table lubricates the manual oil pump as standard.
4、可選配電動儲料配置與開儲同步功能。ZS500及以下機型可選配注射線性導軌。
      Optional electric storage configuration and synchronous function of opening
      and storing. ZS500 and below models can be equipped with injection linear
      guide rail.
5、汽配產品可選配順序注射模塊，無需再另加泵站，生產現場更加安全整潔。
      Auto parts products can be equipped with sequential injection module,
      without additional pumping station, and the production site is safer

      and cleaner.

液壓部分 HYDRAULIC UNIT
1、高排量的液壓系統設計,動力系統加大,注射速度比同類型產品提高
     15%,模循環周期縮短15%,全面提升注塑機表現,可滿足高標準的成
     型要求。
       The hydraulic system design with high displacement, increase
     power system, injection speed and mold cycle time increase 15%
     than the same type products. comprehensively enhance the
     machine can meet high Standrad moulding requirements.
2、油路板分布在各執行元件位置,具有響應速度快,動態性能好。
       Hydraulic manifold are distributed around the execute components,
     having high response.
3、ZS220及以上機型標配數控背壓閥及全系標配油溫檢測顯示，ZS460及以下機型調模標配自鎖馬達。
     The model ZS220 and above comes standard with numerical control
      back pressure valve and oil temperature detection display, and the
      model ZS460 and below comes standard with self-locking motor.

電控部分 CONTROL SYSTEN
1、采用高端電腦主機，控制面板均為彩色大屏幕,時時監測生產進程,
     并顯示各種故障診斷。
     Use high-end computer mainframe control panel with color
     screen to monitor the production process from time to time and
     Displays various troubleshooting.
2、采用新型伺服驅動及電機，提高系統響應速度及精度。
     New servo drive and motor are adopted to improve the response
     speed and accuracy of the system.
3、標配機械手、針閥接線端子排。
     Standard manipulator, needle valve terminal block.
